Our heavy-duty hydraulic coil upender offers a comprehensive solution for safely reorienting materials in industrial settings. Designed for seamless integration with decoiler systems, this equipment efficiently transitions coils between horizontal and vertical positions with precision control.
- The Upender adopts automatic hydraulic system to take the coil to coil car, it is easy and safe way to transition from a horizontal to vertical (and back) orientation to load coil on the mandrel or cradle uncoiler. It is also powered from the hydraulic decoiler and controlled by coil loading car.
- Skidded Coil is Loaded onto Horizontal Platform
- The Platform is Rotated 90 degrees vertically onto loading car
Coil is Raised and lowered to fed into the decoiler mandrel, align with decoiler mandrel (Skid is Removed
Technical Specifications of Machine:
-
Capacity: 15 metric tons (custom configurations available 3-100T)
-
Rotation: 90° vertical tilt (180° horizontal option)
-
Control System: Hydraulic pendant with magnetic starter
-
Safety: Dual limit switches + disc brake system
-
Construction: Reinforced steel frame with full base plate
Operation Sequence of Machine :
-
Horizontal loading of skidded coil
-
Automated 90° rotation to vertical
-
Precision alignment with decoiler mandrel
-
Secure material transfer (skid removal)
Key Advantages of Machine:
-
Integrated hydraulic power from decoiler unit
-
Optional V-cradle attachments for coil stability
-
Forklift-accessible transport pockets
-
Urethane-faced contact surfaces available
-
Custom platform sizing upon request
