90 Degree Horizontal Hanging Board Wall Cladding Roll Forming Machine
In modern steel structure buildings, efficiency, precision, and long-span load capacity have become critical requirements. The 90 Degree Horizontal Hanging Board Wall Cladding Panel Roll Forming Machine is specially designed to meet these demands, offering reliable performance for roof decking and wall cladding applications in both industrial and commercial projects.
With advanced forming technology and an intelligent control system, this machine enables stable, high-speed production while ensuring excellent profile accuracy and long service life.
Large-Span Roof Deck Roll Forming Machine with Independent Load Capacity
The panels produced by this roll forming machine can function as large-span roof decks capable of bearing loads independently. Thanks to their outstanding mechanical properties, they fully support purlinless steel roof structures, reducing material costs and simplifying installation.
In addition, the formed panels are compatible with:
- Rigid thermal insulation materials
- Flexible waterproof membranes
This makes them ideal not only for roofing systems but also as safe working platforms during roof construction, improving overall jobsite efficiency and safety.
Key Advantages of the Roll Forming Machine
1. High-Precision Forming
Using CNC programming and a servo-driven forming system, the machine maintains panel angle accuracy within ±0.3°, meeting the strict standards required for high-end curtain wall and architectural façade projects.
2. High-Efficiency Automatic Production
The fully automatic production line integrates feeding, forming, punching, and cutting in one continuous process.
- Single-shift output: 800–1200 pieces
- Productivity: Up to 4× higher than traditional manual or semi-automatic methods
3. Wide Material Compatibility
The machine supports multiple metal materials, including:
- PPGI / GI / GL
- Aluminum sheets
With a standard thickness range of 0.5–0.8 mm, it balances lightweight design with high structural strength.
Technical Specifications Overview
| Item | Specification |
|---|---|
| Product Name | 90 Degree Horizontal Hanging Board Wall Cladding Roll Forming Machine |
| Applicable Material | PPGI, GI, GL, Aluminum |
| Material Thickness | 0.5 – 0.8 mm |
| Feeding Width | 915 mm |
| Roller Stations | 28 rows (customizable) |
| Shaft Diameter | 80 mm solid shaft |
| Roller Material | 45# steel, hard chrome plated |
| Frame Structure | 350 mm H-beam steel |
| Drive System | Chain transmission |
| Forming Speed | 15–20 m/min |
| Cutting System | Automatic hydraulic cutter, Cr12MoV |
| Main Motor Power | 5.5 kW |
| Hydraulic Power | 4 kW |
| Control System | PLC (Imported brand, multi-language support) |
| Voltage | 380V / 50Hz / 3 Phase (customizable) |
| Machine Size | 10500 × 1600 × 1600 mm (customized) |
| Total Weight | Approx. 7.5 tons |
| Brand | ZTRFM |
| Warranty | 1 Year |
| Export Port | Tianjin Port |
Main Applications
- Building Curtain Walls
Ensures consistent quality and precise angles for high-end architectural projects. - Indoor Partitions & Decorative Walls
Ideal for modern interiors where clean lines and fast installation are required. - Industrial Plants & Warehouses
A practical solution for rapid construction and durable wall cladding systems.
Intelligent Control & Reliable Components
The machine is equipped with an imported PLC control system, allowing operators to easily set:
- Production length
- Batch quantity
- Cutting precision
Core components such as the motor, hydraulic system, and PLC are selected for long service life, low energy consumption, and stable operation, ensuring minimal downtime even in high-output production environments.
Why Choose ZTRFM?
- ISO-certified manufacturing standards
- Proven performance in global markets
- Customized solutions based on project requirements
- Machinery test report & video inspection provided before delivery
The 90 Degree Horizontal Hanging Board Wall Cladding Panel Roll Forming Machine is not just a forming machine—it is a complete, efficient, and future-ready solution for modern roofing and wall cladding systems.
